The KHC-1000 is a robust and reliable humidification system engineered for advanced respiratory support. Designed with three customizable temperature modes and an enhanced alarm system, it ensures safe and consistent humidification for both neonatal and adult patients.
Offers temperature setting modes (P1, P2, P3) to meet varied clinical needs
3-digit, 7-segment LED display for easy temperature visibility and control
Temperature range of 10–70°C, with ±2°C accuracy in the 25–45°C range
Audio and visual alarms for overheat protection and patient safety
Automatic shut-off at 95±6°C for added protection
Built for continuous hospital use with high-performance components
| Parameter | Details |
|---|---|
| Model | KHC-1000 |
| Power Source | AC 220V, 50–60Hz |
| Heated Plate Power | 150 W |
| Max Heating Plate Temp | 85°C |
| Thermal Cut-Off | 95±6°C |
| Display Type | 0.56 inch, 3-digit 7-segment LED |
| Temperature Monitoring Range | 0–75°C |
| Temperature Control Settings | P1: 25–29°C P2: 29–35°C P3: 35–39°C |
| Heated Wire Output | AC 23V, 60W |
| Total Power Consumption | 220W |
| Alarm System | Visual and Audio Alerts |
| Temperature Control Accuracy | ±2°C (within 25–45°C range) |
